GDWN | Gas damper valve wafer normal temperature
Application
For On/Off service
Range
DN 50 – 600
Connection
Wafer: EN1092-1 PN 6/10, ASME 16.5
Inspection & testing
FCI 70-2 Class I & II available (0.5% KV90) EN12266
Temperature range
-40°C / + 400°C
Material
Carbon Steel, AISI304, AISI316, AISI321, …
Design rules
EN12516-1, EN12516-2, ASME B16.34
Face 2 face
Manufacturer standard or according to customer specification
Operated
Handlever, gearbox, pneumatic actuator, electrical actuator
